The CF230 is Monitor Audio’s most visually discreet speaker system, providing an abundance of design possibilities for integrators, architects and installers. Its ingeniously designed retrofit and pre-construction make it a dream to install, while its C-CAM-based driver array delivers the superb audio this British maker is famed for.
Products specifications
|
Product Type
|
In-Ceiling |
|
Power Handling
|
10-30 Watts (full range)
10-100 Watts (Using High Pass crossover filter @120 Hz) |
|
X-Way
|
2-way |
|
Frequency Response
|
100 Hz – 25 kHz |
|
Sensitivity
|
82.5 |
|
Impedence
|
8 Ohms |
|
Diameter
|
4.41" |
|
Cut-Out Dimension
|
3.54 |
|
Bracket
|
CFB3R; CFB3SQ OR CFB3KIT |
|
Length
|
N/A |
|
Width
|
3.29" |
|
Height
|
N/A |
|
Weight
|
0.77lbs |
|
Tweeter Type
|
C-Cam Gold Dome |
|
Tweeter Size
|
0.75" |
|
Midrange Type
|
C-CAM |
|
Midrange Size
|
3" |
|
Woofer Type
|
N/A |
|
Woofer Size
|
N/A |
|
Bass Alignment
|
Infinite Baffle |
|
Finish
|
White Grilles |
